600mm T8 LED Tube Light

Model No.: LGS-TL01-060-10w

Power: 10W

Input Voltage: AC100-240V

Dimension: Φ26*600mm
Light source: SMD2835
CRI: >80Ra
CCT: 2700-6500K
Lifespan: 50,000hrs
Certification: CE,RoHS
Warranty: 3 years

  • Description
  • Specifications
  • Learn More
  • Inquiry

Features

– Up to 70% energy saving compared to traditional tube;
– Long lifetime of 50,000 hours;
– 120°wide beam angle;
– No UV/IR light, environment friendly, without Mercury or any other hazardous substances;
– No noise during working;
– High power factor >0.95.

Product Details

led tube light detail

Specifications

Product NameLED Tube Light
Model No.LGS-TL01-060-10W








Optical

LEDsSMD2835
Lumen Output1100lm±10%
Luminous Efficiency(lm/w)110lm/w
Color Temperature(CCT)2700-6500K
Color Rendering Index(CRI)Ra>80
Beam Angle θ/2120°
Light Decay Rate(%)Less than 3% in 6,000Hours
Lifespan(Hrs)≥50,000Hrs




Electrical

Power Consumption(W)10W±10%
Input Voltage(V)100-240VAC
Frequency(Hz)50/60Hz
Power Factor(PF)>0.9
Start Time(s)≤0.1s
Driver Efficiency>87%
THD<20%




Mechanical

MaterialAluminum+PC
Degree of ProtectionIP20
Dimensions(mm)Φ26*600mm
Lamp HolderG13




Other

Working Tem. & Humidity-30℃~+50℃,10%~90%R.H.
Storage Temp. & Humidity-40℃~+70℃,0%~95%R.H.
CertificateCE, RoHS
Warranty3 years



Light Distribution Curve

ed tube light distribution Curve



Dimensions
led tube light dimmension-600

Applications

Widely used for various commercial lighting and residential lighting applications, such as offices, shopping mall, hotel, restaurant, hospital, home lighting, etc.

Installations

Installation with inductive ballast

led tube light installation with inductive ballastInstallation with electronic ballastled tube lgiht installation with electronic ballast



Package

led tube light packing

Notice

1. Please use the product within the specified range of voltage;
2. Please follow the correct installation steps to install the product, and do not touch when it is working;
3. Please turn power off when installing and removing the products to avoid risk of electric shock;
4. Please install the tube in the correct sized fixture;
5. Do not look directly at LED light source for a long time.
